Rotary Sample Divider
A perfect and comparable analysis is closely related to the correct sampling. Based on that, rotary sample divider is designed for sampling, dustless separation and reduction of large quantities of powder or granular bulk materials.
This machine is used in various area such as materials Portland cement clinker, chemicals,construction materials, fertilizers, fillers, flours, grains, metal powders, minerals, nut, sand, seeds, soil, dust washingetc. in areas of agriculture, biology, chemical, plastic, building materials, engineering, electronic, environment, recycling, food,geology, metallurgy, glass, ceramic.
The added material is divided equally into the buckets which rotating in a "circle" motion.
Sample buckets are made of 304 quality stainless steel with a sheet thickness of 2 ± 01 mm and are made up of 8 divisions, each with 10 ltchambers in triangular prism shape. Depending on demand, production can be done in special dimensions.
The feeding chamber is made of 304 quality stainless steel, and the other parts are made of electrostatic powder paint on steel.
Sample buckets have handles to easy and safe carrying.
Feeding speed and quantity are adjustablesteplessly with the help of magnetic vibration system.
Samplefeedingsystem is vibratory.Feedingsystemcan be adjustedwith horizontal to 0°C and 10 °C from the base of the device.
Dividingspeed of samplebucketscan be adjusted between 0 and 60 rpm steplessly with electronic speed control panel.
The samplebuckets can be rotated with the rotation adjusted drive motor.
The samplebucketsareattached to each other with removable, made of steel suitable material with edge of the buckets to avoid the material coming from the feeder during the sample flow to the gap between sample buckets.
Sample feeding Speed can be adjusted steplessly by vibration coil and variac system.
Rotary table control and vibration control panel is easy to use.
Thegrain size capacity of theRotarySampleDivider is 0-50 mm.
RotarySampleDivider is equippedwitha mobile chassis on four wheels and has a stabiliser safety system on the wheel.
This machine is used in various area such as materials Portland cement clinker, chemicals,construction materials, fertilizers, fillers, flours, grains, metal powders, minerals, nut, sand, seeds, soil, dust washingetc. in areas of agriculture, biology, chemical, plastic, building materials, engineering, electronic, environment, recycling, food,geology, metallurgy, glass, ceramic.
The added material is divided equally into the buckets which rotating in a "circle" motion.
Sample buckets are made of 304 quality stainless steel with a sheet thickness of 2 ± 01 mm and are made up of 8 divisions, each with 10 ltchambers in triangular prism shape. Depending on demand, production can be done in special dimensions.
The feeding chamber is made of 304 quality stainless steel, and the other parts are made of electrostatic powder paint on steel.
Sample buckets have handles to easy and safe carrying.
Feeding speed and quantity are adjustablesteplessly with the help of magnetic vibration system.
Samplefeedingsystem is vibratory.Feedingsystemcan be adjustedwith horizontal to 0°C and 10 °C from the base of the device.
Dividingspeed of samplebucketscan be adjusted between 0 and 60 rpm steplessly with electronic speed control panel.
The samplebuckets can be rotated with the rotation adjusted drive motor.
The samplebucketsareattached to each other with removable, made of steel suitable material with edge of the buckets to avoid the material coming from the feeder during the sample flow to the gap between sample buckets.
Sample feeding Speed can be adjusted steplessly by vibration coil and variac system.
Rotary table control and vibration control panel is easy to use.
Thegrain size capacity of theRotarySampleDivider is 0-50 mm.
RotarySampleDivider is equippedwitha mobile chassis on four wheels and has a stabiliser safety system on the wheel.
